Extrusion Blow Molding Machine
Do you want to find a suitable extrusion blow molding machine supplier as your partner? You can get the top quality of China with excellent service and price.
Let us help you find the extrusion blow molding machine that's right for you!
Contact us today for expert advice and assistance
Shape the Future with Our Cutting-Edge Extrusion Blow Molding Machine!
🔧Precision Engineering🔧
Built with the latest technology, our extrusion blow molding machine offers unmatched precision and accuracy in every production cycle.
🚀Versatile & Flexible🚀
Capable of molding a wide range of shapes and sizes, our machine adapts to your changing needs with ease. From small prototypes to large-scale production, we've got you covered.
🌱Eco-Efficient🌱
Focused on sustainability, our extrusion blow molding machine is designed for optimal energy efficiency, reducing waste and minimizing environmental impact.
💼Comprehensive Support💼
Backed by a team of experts, we provide comprehensive support and maintenance services to ensure your machine operates smoothly, round the clock.
Embrace innovation and take your production to the next level with our extrusion blow molding machine!
Reach out to us today for a quote and more information.
Model | ABLB 45 | ABLB 55 | ABLB 65 | ABLB 75 | ABLB 80 | ABLB 90 | ABLB 100 | ABLB 82PC |
Max. product volume(L) | 2 | 3.5 | 5 | 8 | 10 | 16 | 30 | 25 |
Dry cycle(PC/H) | 1300 | 1100 | 1000 | 800 | 700 | 700 | 600 | 360 |
Screw diameter(mm) | 45 | 55 | 65 | 75 | 80 | 90 | 100 | 82 |
Screw L/D ratio(L/D) | 24 | 24 | 24 | 24 | 24 | 24 | 25 | 25/30 |
Screw drive power(Kw) | 11 | 15 | 18.5 | 22 | 30 | 37 | 55 | 10-80 |
Screw heating capacity(Kw) | 3-4 | 5-6 | 5-6 | 7-8 | 8-9 | 10 | 15 | 30 |
No.of heating zone | 3 | 3 | 3 | 4 | 4 | 4 | 4 | 5 |
Output of HDPE(Kg/h) | 30 | 60 | 75 | 100 | 110 | 130 | 200 | 160(PC) |
Oil pump drive power(Kw) | 5.5 | 5.5 | 7.5 | 7.5 | 11 | 11 | 15 | 45*2 |
Clamping force(KN) | 35 | 45 | 65 | 80 | 100 | 160 | 230 | 220 |
Max.size of mold(mm) | 250*320 | 300*330 | 320*350 | 400*430 | 400*550 | 530*550 | 600*660 | 700*800 |
Template size(mm) | 290*320 | 290*320 | 290*320 | 380*420 | 400*540 | 550*550 | 600*655 | 800*800 |
Mold stroke(mm) | 150-500 | 150-500 | 150-500 | 170-520 | 170-520 | 320-620 | 420-920 | 8.7 |
Max.die diameter(mm) | 120 | 140 | 170 | 170 | 200 | 200 | 250 | 83 |
Blowing pressure(Mpa) | 0.6 | 0.6 | 0.6 | 0.6 | 0.8 | 0.6 | 0.8 | 8 |
Air volume(M³/Min) | 0.4 | 0.5 | 0.6 | 0.7 | 0.8 | 0.7 | 1.2 | 0.8 |
Cooling water pressure(Mpa) | 0.3 | |||||||
Water consumption(L/Min) | 30 | 40 | 50 | 60 | 80 | 70 | 120 | 80 |
Size of machine(L*W*H) | 3.4*1.8*2.2 | 3.4*1.8*2.2 | 3.9*2.0*2.6 | 4.2*2.0*2.7 | 4.4*2.0*2.7 | 4.3*2.2*3.0 | 5.0*3.0*3.2 | 5.6*2.7*4.5 |
Weight of machine(Ton) | 4.5 | 4.8 | 5.5 | 6.8 | 7.5 | 8 | 15 | 11.8 |
Model | ABLD 80 | ABLD 90 | ABLD 100 | ABLD 110 | ABLD 120 | ABLD 150 |
Max.product volume(L) | 30 | 60 | 120 | 160 | 220 | 1500 |
Dry cycle(PC/H) | 600 | 450 | 360 | 300 | 300 | 300 |
Screw diameter(mm) | 80 | 90 | 100 | 110 | 120 | 120*2 |
Screw L/D ratio(L/D) | 25 | 25 | 28 | 28 | 33 | 33 |
Screw drive power(Kw) | 37 | 45 | 55 | 75 | 132 | 132*2 |
Screw heating capacity(Kw) | 16 | 18 | 22 | 25 | 36 | 36*2 |
No.of heating zone | 4 | 4 | 5 | 5 | 6 | 6*2 |
Output of HDPE(Kg/h) | 120 | 150 | 200 | 240 | 350 | 620-840 |
Oil pump drive power(Kw) | 15 | 15 | 22 | 30 | 37 | 37 |
Clamping force(KN) | 210 | 320 | 600 | 900 | 900 | 1800 |
Max.size of mold(mm) | 700*900 | 800*1200 | 1000*1300 | 1000*1600 | 1200*1700 | 1600*2200 |
Material storage(L) | 4.4 | 6.6 | 14 | 20 | 24-35 | 40-100 |
Template size(mm) | 750*800 | 900*900 | 1150*1300 | 1150*1600 | 1200*1600 | 1600*2000 |
Mold stroke(mm) | 350-900 | 450-1100 | 550-1350 | 550-1350 | 880-1700 | 800-2500 |
Max.die diameter(mm) | 280 | 340 | 450 | 650 | 700 | 1000 |
Die head heating power(Kw) | 15 | 18 | 21 | 25 | 36 | 64 |
Die heating few segments | 4 | 4 | 5 | 5 | 6 | 8 |
Blowing pressure(Mpa) | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 1.2 |
Air volume(M³/Min) | 1.0 | 1.2 | 1.6 | 1.6 | 1.6 | 6 |
Cooling water pressure(Mpa) | 0.3 | |||||
Water consumption(L/Min) | 60 | 90 | 150 | 150 | 180 | 240 |
Size of machine(L*W*H) | 4.4*2.6*3.8 | 5.2*2.9*4.6 | 5.4*2.5*4.5 | 5.8*3.2*4.8 | 7.5*3.5*5.5 | 11.5*7.5*8 |
Weight of machine(Ton) | 11 | 13.5 | 15 | 20 | 36 | 72 |
